레벨센서

– 적용분야 : 세탁기 수위센서, 칠러 냉각수 레벨센서.

AP-20DT_ver3.2.1

Download
– Output : I2C
– Power Supply : 5VDC
– Electric connection : 6.4Ø T형
– Process connection : 4P connector
– Pressure Range : 0~4bar
– Operating Temp. Range : -20 to 80℃
– Accuracy : ≤±1%F.S[Typical/25℃]

AP-20D_ver3.2.2

Download

– Output : I2C
– Power Supply : 5VDC
– Electric connection : 1/4-28UNF
– Process connection : 4P connector
– Pressure Range : 0~600mmH2O
– Operating Temp. Range : -20 to 80℃
– Accuracy : ≤±1%F.S[Typical/0~50℃]

ABS001-A

Download
– Type : Three-plug water level sensor
– Character : Double capacitro Three-plug

– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS002

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS003

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS005

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS006

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS008

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column

ABS009

Download
– Type : Two-plug water level sensor
– Character : Single capacitro Two-plug
– Structural description : Without mounting bracket

– Operation Voltage : DC5V
– Environment : -10 to 50℃
– Water level range : 0~600mm Water column
